DPST 1NO 1NC 8Amp Latching Relay Module (DC 5V)
DPST 1NO 1NC 8Amp Latching Relay Module (DC 5V)
DPST 1NO 1NC 8Amp Latching Relay Module (DC 5V)
DPST 1NO 1NC 8Amp Latching Relay Module (DC 5V)
DPST 1NO 1NC 8Amp Latching Relay Module (DC 5V)
DPST 1NO 1NC 8Amp Latching Relay Module (DC 5V)
genuine image
DPST 1NO 1NC 8Amp Latching Relay Module (DC 5V)
DPST 1NO 1NC 8Amp Latching Relay Module (DC 5V)
DPST 1NO 1NC 8Amp Latching Relay Module (DC 5V)
DPST 1NO 1NC 8Amp Latching Relay Module (DC 5V)
DPST 1NO 1NC 8Amp Latching Relay Module (DC 5V)
DPST 1NO 1NC 8Amp Latching Relay Module (DC 5V)
DPST 1NO 1NC 8Amp Latching Relay Module (DC 5V)
This latching relay has power-off memory and supports three input control modes.
DPST 1NO 1NC 8Amp Latching Relay Module (DC 5V)
Artikelnr.: 32885774

DPST 1NO 1NC 8Amp Latching Relay Module (DC 5V)

Artikelnr.: 32885774

ANG 57

Prijsdetails

Exclusief verzend- en douanekosten ( Verzend- en douanekosten worden berekend bij het afrekenen )

*Alle artikelen worden geïmporteerd vanuit VS

Op voorraad
VS Geïmporteerd uit USA

QTY:

Nog slechts 6 artikelen op voorraad.
Bestel nu en ontvang het rond Vrijdag, Augustus 21
Beveiligde transactieBeveiligde transactie

Ubuy zet zich in om uw veiligheid en privacy te beschermen. Ons geavanceerde beveiligingssysteem voor betalingen zorgt voor vertrouwelijkheid door uw gegevens tijdens verzending te versleutelen met AES (Advanced Encryption Standards) en SSL (Secure Socket Layer) protocollen. Uw betalingsgegevens zijn 100% veilig, aangezien wij uw betalingsgegevens niet delen met externe verkopers.

Onze beste bezorgdiensten
  • fedex
  • dhl
This latching relay has power-off memory and supports three input control modes.
Meer weergeven
U-Care-garantie:
Geen
Selecteer een abonnement
fast shipping

Spoedbestelling

free return

Gratis
retourneren*

Stevig verpakt

Stevig verpakt

100% Origineel product

100% Origineel product

pci-dss

PCI DSS Compliance

iso certified

ISO 27001 Certified

paypal payment
visa payment
mastercard payment

Wat opvalt

Latching Functionality
This relay module retains its state even after power loss, reducing energy consumption and enhancing reliability in applications that require maintaining status over time.
Dual Contact Design
With both Normally Open (NO) and Normally Closed (NC) contacts, this module provides versatile control options, making it suitable for a wide range of circuit applications.
High Current Rating
Rated for 8Amps, the relay module can handle substantial loads, ensuring performance efficiency and reliability for various high-power applications without the risk of overheating.

Productdetails

Shop DPST 1NO 1NC 8Amp Latching Relay Module (DC 5V) online at a best price in curacao. B08R7BGBYQ
  • If you are looking for a latching relay with power-off memory, then this module will be very suitable for you. Even if the power supply is turned off, the status of the output switch will not be affected in any way, it will remain in the state before the power was turned off.
  • This is a simple and practical latching relay module, which is very convenient to use. It can support both Normally Open and Normally Close. Two screw mounting holes are convenient for you to fix it on the wall or wooden board. Of course, you can also choose not to lock the screw. Compact plastic case and wires connects for easy mount.
  • Support three input control modes: 1, Use Set and Reset buttons on the module(No external control switch or signal is required). 2, External Set and Reset button(Support Momentary-action switch, but can't support Self-holding switch). 3, for Sink/NPN output controller.
  • Operating voltage version: DC 5V, 12V and 24V three versions selectable. Output switch DPST 1NO 1NC(Double Pole Single Throw, 1x Normally Open and 1x Normally Close ), rated current 8A/250VAC or 8A/30VDC (for one switch).
Connector TypeScrew
Contact Type1no 1nc
Current Rating8 A
Mounting TypeScrew Mount
Operation ModeOff
Wattage40 watts
Coil Voltage5 volts
Contact Current Rating8 A
Maximum Switching Current8 A
Minimum Switching Voltage5 volts_of_direct_current
Brand NameOONO
Unit Count1 Count
ManufacturerCZH-LABS
ModelF-1030 Series
Part NumberF-1030 Series
Contact MaterialSilver Alloy
Item Weight0.5 lbs (230 grams)

Voor wie is dit geschikt?

Suitable For
  • DIY Electronics Hobbyists

    Ideal for hobbyists looking to control devices with low voltages using a reliable switching mechanism.

  • Automation Projects

    Suitable for various automation projects that require effective switching in smart home or industrial setups.

  • Arduino Users

    Perfect for Arduino users needing a latching relay to manage high-power loads in their projects.

Not Suitable For
  • High Voltage Applications

    Not suitable for applications requiring higher voltage ratings beyond the module's 5V specification.

PRODUCTBESCHRIJVING

Heeft u een vraag? Chat met ons

Vragen en antwoorden van klanten

  • vraag: What is a DPST 1NO 1NC latching relay module?

    antwoord: A DPST (Double Pole Single Throw) 1NO (One Normally Open) 1NC (One Normally Closed) latching relay module is an electrical component used to control high-power devices using a low-power signal. This type of relay can switch circuits on and off without needing continuous power, making it energy-efficient. It is commonly used in applications like automation systems, DIY electronics projects, and remote control devices, allowing users to operate lights, motors, and other equipment reliably.
  • vraag: How does a latching relay work?

    antwoord: A latching relay maintains its position after the triggering signal is removed. This means that when activated, it will stay switched on until it receives a second signal to turn off. This characteristic is beneficial for low-power control applications, as it reduces energy consumption since it doesn't require a constant input to maintain the circuit. Practical uses include smart home systems, where you can control devices remotely without having to keep pressing buttons or switches.
  • vraag: What are the main features of the DPST 1NO 1NC latching relay module?

    antwoord: The main features of the DPST 1NO 1NC latching relay module include its ability to handle loads up to 8Amps at 5V DC, two independent circuits for flexibility, and the simple integration into microcontroller projects such as Arduino or Raspberry Pi. This versatility makes it ideal for various automation tasks, such as turning on multiple devices with a single command or implementing safety features during device operation.
  • vraag: What applications are ideal for using a DPST latching relay?

    antwoord: DPST latching relays are suitable for various applications, including home automation projects, industrial controls, and smart home devices. They can be used to operate various loads such as lights, heaters, or motors, allowing users to create on/off control systems without constant power consumption. For instance, in home automation, you can set up remote control options for lights or appliances, ensuring energy-efficient management.
  • vraag: How can I connect a DPST 1NO 1NC relay module to my microcontroller?

    antwoord: To connect the DPST 1NO 1NC relay module to a microcontroller, follow these steps: connect the trigger pins to a digital output pin on the microcontroller, then connect the common terminals to your load. Make sure to provide appropriate power to the module, typically at 5V DC. This setup allows the microcontroller to control high-voltage devices while safeguarding its components against high currents. This configuration is widely used in DIY electronic projects and robotics.
  • vraag: Are DPST latching relays easy to integrate with Arduino?

    antwoord: Yes, integrating a DPST latching relay with Arduino is straightforward. By using a few jumper wires, a simple code snippet, and the relay's trigger pins, users can easily manage multiple outputs from their Arduino. This is particularly useful for creating complex automation systems, such as lighting controls or motorized appliances, allowing for efficient control without constant power needs. With libraries available specifically for Arduino, setup and coding become even easier.
  • vraag: What safety precautions should I take while using latching relays?

    antwoord: When using latching relays, ensure that the load does not exceed the relay's power rating and always use appropriate fuses for protection. It's important to isolate the high and low voltage sections of your circuit to prevent damage and hazards. Additionally, proper grounding and following installation guidelines will enhance safety and reliability, which is critical in applications such as home automation or industrial systems.
  • vraag: Can I control multiple devices with one DPST latching relay?

    antwoord: Yes, a DPST latching relay can control multiple devices concurrently because it has two independent switches. By wiring different devices to the relays' outputs, you can operate them simultaneously. This flexibility is beneficial for building automation solutions where multiple appliances need to be controlled through a singular interface, improving the overall efficiency of your system.
  • vraag: Do I need additional components to use the relay with my project?

    antwoord: Typically, you might need additional components depending on your project requirements, such as resistors, diodes for flyback protection, and potentially a transistor to drive the relay if your microcontroller's output can't handle the relay coil's current. Additionally, using a power supply that meets the relay's voltage requirements ensures proper operation. These components will help ensure a smooth functioning of your project's relay system.
  • vraag: Where can I buy DPST 1NO 1NC 8Amp Latching Relay Module DC 5V?

    antwoord: You can buy the DPST 1NO 1NC 8Amp Latching Relay Module DC 5V from Ubuy. Ubuy offers a wide range of electronic components, including various relay modules, making it a reliable choice for sourcing the right components for your projects.

OONO Electromechanical Relays Editorial Review

The latching relay module is designed for DC power sources and can be switched from the negative (ground) side to latch or unlatch the module. It remembers the previous state on power loss but can be modified to reset on start-up. Multiple momentary set and reset switch pairs wired in parallel can control the module. It comes with a protection diode across the relay coil. Customer reviews have been mixed. Some are disappointed as the product arrived broken/faulty or didn't work, and no directions were included. Others have had success with the product, and it does what it's supposed to do. One review mentioned that they had to add a resistor transistor circuit to reverse the incoming trigger as it needs a negative trigger, and they needed to use +5V. Another review stated that no quiescent current draws, and it works great. Overall, the module is compact, and the pigtail wires are better than the cheap knock-off connectors.

Klantbeoordelingen en -waardering

6 klantenbeoordelingen
  • 5 ster
    73%
  • 4 ster
    27%
  • 3 ster
    0%
  • 2 ster
    0%
  • 1 ster
    0%

Beoordeel dit product

Deel uw mening met andere klanten

Voordelen

  • Can be controlled by multiple momentary set and reset switch pairs wired in parallel.
  • Comes with a protection diode across the relay coil.
  • Draws no current after initial set-reset pulse.
  • Small and compact.

Nadelen

  • Mixed reviews.

VERTROUWEN IN HET PLATFORM & KOPERSZEKERHEID

trustpilot logo
4.2/5 9250 + reviews
Recensies lezen
MA
Mohammad
Geverifieerde koper

“Excellent quality and original too,when ubuy send original things I will appreciate that ,I very satisfied thank you”

23 July 2026 · via Trustpilot
CK
Chitra
Geverifieerde koper

“The order and delivery progress was communicated very well. Package arrived within the estimated time. Products arrived as expected in good condition.”

22-Jul-26 · via Trustpilot
K
kund
Geverifieerde koper

“Good supply of products. Safe payment methods, and shipment worldwide! Genuine products.”

23-Jul-26 · via Trustpilot
OO
Onesi
Geverifieerde koper

“Was my first time buying a product from Ubuy, but I found it so helpful. This is reliable. Gonna place a new order!”

22 July 2026 · via Trustpilot
SJ
SAO JOHN
Geverifieerde koper

“Ubuy is a great online platform to buy stuff. Reliable, fast delivery time and great value for money. I've been using Ubuy online shopping platform for three years now and will continue to do so.”

23 July 2026 · via Trustpilot
Veilig Afrekenen Wereldwijde levering Eenvoudig retourneren Originele producten

Prijsgeschiedenis van het product

Belangrijke informatie

  • Beperkingen: voor producten die internationaal worden verzonden, gelieve er rekening mee te houden dat eventuele fabrieksgaranties mogelijk niet geldig zijn; ondersteuningsopties van de fabrikant zijn mogelijk niet beschikbaar; producthandleidingen, instructies en veiligheidswaarschuwingen zijn mogelijk niet in de taal van het land van bestemming; de producten (en bijbehorende materialen) zijn mogelijk niet ontworpen in overeenstemming met de normen, specificaties en etiketteringsvereisten van het land van bestemming; en de producten zijn mogelijk niet in overeenstemming met de voltage- en andere elektriciteitsstandaarden van het land van bestemming (waardoor het gebruik van een adapter of omvormer nodig is, indien van toepassing). De ontvanger is ervoor verantwoordelijk zich ervan te verzekeren dat het product rechtmatig kan worden geïmporteerd naar het land van bestemming. Bij het bestellen bij Ubuy of diens partners geldt de ontvanger als de geregistreerde invoerder en dient zich als zodanig te houden aan alle wetten en voorschriften van het land van bestemming.
  • Omdat Ubuy een wereldwijde zoekmachine is, zijn niet alle producten die op Ubuy worden vermeld ook te koop. Producten zijn onderworpen aan wetgeving inzake export en handel.

ANG 57

Bestel nu en ontvang het rond Vrijdag, Augustus 21

QTY:

Nog slechts 6 artikelen op voorraad.
Beveiligde transactieBeveiligde transactie

PCI DSS-compliant en ISO 27001:2022-gecertificeerd, met versleutelde betalingen en volledige kopersbescherming bij elke bestelling.

Onze beste bezorgdiensten
  • fedex
  • dhl
Snelste grensoverschrijdende levering

Kenmerken en voordelen

  • Power-off memory for maintaining output switch status
  • Supports both Normally Open and Normally Close modes
  • Compact plastic case, with screws for easy mount
  • Supports three input control modes
  • Operating voltage versions available for DC 5V, 12V and 24V
  • Rated current 8A/250VAC or 8A/30VDC for one switch.
